Ortofon SPU Classic N SPU Phono Cartridge
by Ortofon
UPC: 5705796240221
Call for Availability
$939.00
SKU SPUClassicN
Product Qualifies for FREE Ground Shipping
The SPU Classic N provides the same sound reproduction properties as the SPU Classic GM series
The SPU Classic N is sold without the integrated headshell unit.
The SPU Classic N is a Moving Coil (MC) cartridge with an 18 m spherical stylus profile.
Listeners who wish to mount the SPU Classic on a traditional headshell may do so by using SPU N adaptor. Those with vintage SPU-type headshells can use the Classic N to recreate an authentic and functional SPU cartridge. NB: Vintage SPU-type headshells are no longer available.
Output voltage at 1000 Hz, 5cm/sec. - 0.2 mV
Channel balance at 1 kHz - < 1 dB
Channel separation at 1 kHz - > 20 dB
Channel separation at 15 kHz - > 10 dB
Frequency range at - 3dB - 20-25.000 Hz
Frequency response - 20-20.000 Hz 3 dB
Tracking ability at 315Hz at recommended tracking force *) - 65 m
Compliance, dynamic, lateral - 8 m/mN
Stylus type - Nude spherical
*) Typical value
Stylus tip radius - R 18 m
Tracking force range - 3.0-5.0 g (30-50 mN)
Tracking force, recommended - 4.0 g (40 mN)
Tracking angle - 20
Internal impedance, DC resistance - 6 Ohm
Recommended load impedance - > 10 Ohm
Coilwire material - High Purity Copper (OFC)
Cartridge colour - Black
Cartridge weight - 13 g
The SPU Classic N is sold without the integrated headshell unit.
The SPU Classic N is a Moving Coil (MC) cartridge with an 18 m spherical stylus profile.
Listeners who wish to mount the SPU Classic on a traditional headshell may do so by using SPU N adaptor. Those with vintage SPU-type headshells can use the Classic N to recreate an authentic and functional SPU cartridge. NB: Vintage SPU-type headshells are no longer available.
Specs
Technical dataOutput voltage at 1000 Hz, 5cm/sec. - 0.2 mV
Channel balance at 1 kHz - < 1 dB
Channel separation at 1 kHz - > 20 dB
Channel separation at 15 kHz - > 10 dB
Frequency range at - 3dB - 20-25.000 Hz
Frequency response - 20-20.000 Hz 3 dB
Tracking ability at 315Hz at recommended tracking force *) - 65 m
Compliance, dynamic, lateral - 8 m/mN
Stylus type - Nude spherical
*) Typical value
Stylus tip radius - R 18 m
Tracking force range - 3.0-5.0 g (30-50 mN)
Tracking force, recommended - 4.0 g (40 mN)
Tracking angle - 20
Internal impedance, DC resistance - 6 Ohm
Recommended load impedance - > 10 Ohm
Coilwire material - High Purity Copper (OFC)
Cartridge colour - Black
Cartridge weight - 13 g
